DLS2-60-070-1-B-24V

Item No.: 167.0629

Diffused Illumination

DLS SERIES - Diffused square illumination

DLS Series provide diffused even illumination over a surface. The even illumination prevents glaring for reflective surface.

Applications: character recognition on shining surface, lead inspection, barcode/OCR foil inspection

Full technical specifications: Click here to download

€437,00
(Price excluding VAT)
EAN
7435847312383
Type of illumination
Diffused
Shape
Square
Angle
60
Colour
Blue
Voltage Input
24V
Size
70
Brand
TMS Lite
Series
DLS

Specification

- Colour Blue

- Length 70mm

- Angle 60°

- Continuous and Strobe Applications

- Lighting Cable 500mm

Technical Information

24V DC Input Power

Voltage/Watt                Current

24V / 4.32 W (Blue)     180mA

LED 470nm
