LLA-60-070-2-B-12V

Item No.: 167.1239

LLA-60-070-2-B-12V, Direct Illumination

LLA SERIES - Low angle darkfield illumination

LEDs are arranged in low angle to provide side illumination.

Optional diffuser can be added to this LLA light for more even light distribution.

Applications: edge detection, scratched on metal or glossy surface

369,00
(Price excluding VAT)
Features
Type of illumination:
Direct
Shape:
Ring
Angle:
60
Colour:
Blue
Voltage Input:
12V
Size:
70
Brand:
TMS Lite
Series:
LLA

Specification

- Colour Blue

- Length 70mm

- Angle 60°

- Continuous and Strobe Applications

- Lighting Cable 500mm

Technical Information

24V DC Input Power

Voltage/Watt                   Current

24V / 5.40 W (Blue)        450 mA

LED 470 nm
