LLA-60-150-3-B-24V

Item No.: LLA-60-150-3-B-24V

Direct Illumination

LLA SERIES - Low angle darkfield illumination

LEDs are arranged in low angle to provide side illumination.

Optional diffuser can be added to this LLA Light for more even light distribution.

Applications: edge detection, scratched on metal or glossy surface

Full technical specifications: Click here to download

583,00
(Price excluding VAT)
Diffuser
Extension cable
Polarizer
Features
Type of illumination:
Direct
Shape:
Ring
Angle:
60
Colour:
Blue
Voltage Input:
24V
Size:
150
Series:
LLA

Specification

- Colour Blue

- Length 150mm

- Angle 60°

- Continuous and Strobe Applications

- Lighting Cable 500mm

Technical Information

24V DC Input Power

Voltage/Watt                   Current

   24V / 15.12 W (Blue)        630 mA

LED 470 nm

Recommended products:
