DCM BKL0303A-850S

Item No.: 230.0426

DCM BKL0303A-850S, Diffuse backlight illumination

DCM BKL0303A-850S - Diffuse backlight illumination

The BKL is a diffuse backlight illumination, designed for applications where strong light-dark contrast is essential to clearly visualize shapes, edges, and profiles. By evenly illuminating the object from behind, a sharp silhouette is created, ideal for machine vision applications such as contour detection, edge inspection, and profile measurement.

The aluminum housing of the illumination is designed for maximum heat dissipation.

Technical specifications: Click here to download

Made in Europe

192,60
(Price excluding VAT)
EAN
7435856120153
Type of illumination
Backlight
Shape
Square
Angle
0
Voltage Input
24V
Colour
IR850
IP
40
Size
30x30
Brand
DCM Sistemes
Series
BKL

Specification

- Colour IR

- IP 40

- Size 30x30 mm

- Strobe Applications

- 2P Cable

Technical information

24V DC Input Power

Voltage/Watt

24V / 200mA/4.8W
