DTCM111-90-AL

Item No.: 238.0113

DTCM111-90-AL

Coolens DTCM111-90-AL - C-Mount Bi-Telecentric Lens

• FOV ⌀ 90mm, Ultra Resolution Bi-Telecentric Lens

• Up to 25 MegaPixels, 2.5 μm Pixel Size Sensors

• 1.1" Bi-Telecentric Lens, C-Mount

• Magnification (x) 0.204

1.603,00
(Price excluding VAT)
Features
Brand:
Coolens
FNO:
F 6.2
Sensor Type:
1.1 Inch
Mount:
C-mount
Megapixel:
25MP
Series:
Telecentric
FOV:
90 mm

Specification

FOV: 90 mm ⌀

Max Sensor Size: 18.4 mm (1.1")

Typical Telecntricity: <0.1

MTF30: >145 lp/mm

I/O length: 472 +/- 3 mm

Dept of Field: +/- 10.5 (@F11)

Length: 246.7 mm

Magnification: (x) 0.204

Working Distance: 208 +/- 3 mm

Aperture: F6.2

Typical Distortion: max <0.1%

C-mount
