MVA Datalogic Impact Basic – Classroom Training

MVA Datalogic Impact Basic – Classroom Training

Machine Vision Academy

The MVA Datalogic Impact Basic is a three-day, hands-on machine vision training course for engineers and technicians who want to develop inspection applications independently using Datalogic Impact. The training is suitable for users of Datalogic P2X and P3X smart cameras and MX-E vision systems.

During the training, you will learn how to build a complete machine vision application. We start by defining the inspection task and then cover the selection of the camera, sensor, lens and lighting. Topics include Field of View, pixel resolution, working distance, optical resolution, contrast and motion blur.

You will then build inspection applications in Impact VPM and create a simple operator interface in CPM. Practical applications include presence inspection, position inspection, measurement, barcode and DMC inspection, and pass/fail inspection. Triggering, digital I/O and communication with a PLC or machine control system are also covered.

After completing the training, you will be able to independently develop, test and modify basic Datalogic Impact applications. You will understand not only how the software tools work, but also how the camera, lens, lighting, triggering and mechanical setup together determine the reliability of an industrial vision inspection.

The course is delivered as classroom training and combines technical instruction, practical examples and hands-on exercises. Course materials, training images and example programs are included.

€1.495,00
(Price excluding VAT)
Request a quotation

Additional information

The training lasts three days and combines technical instruction, practical examples and hands-on exercises. During the training, you will work with Datalogic Impact VPM and CPM.

Topics

  • Analysing and structuring an inspection task

  • Determining the Field of View, pixel resolution and required inspection accuracy

  • Choosing between a P2X or P3X smart camera and an MX-E system

  • Calculating working distance, magnification and focal length

  • Selecting the right lens and machine vision lighting

  • Understanding the effects of lighting colour, reflections and contrast

  • Exposure time and motion blur

  • Triggering with a photoelectric sensor or PLC

  • Digital I/O and processing pass/fail results

  • Building an inspection program in Impact VPM

  • Creating a simple operator interface in CPM

Impact tools

The following tools are used during the practical exercises:

  • Contrast Tool

  • Origin Tool

  • Blob Tool

  • PinPoint Tool

  • Gauge Tool

  • Line Find Tool

  • Circle Tool

  • Barcode Tool

  • DMC Tool

  • Datalog Tool

  • Pass/Fail Tool

  • Digital Output Tool

  • I/O Tool

Practical exercises

Participants build several applications themselves, including:

  • Presence and absence inspection

  • Position and orientation inspection

  • Label inspection

  • Dimensional and shape inspection

  • Barcode and DMC inspection

  • Pass/fail inspection

Included

  • Three days of classroom training

  • Course materials and handouts

  • Training images and practical exercises

  • Datalogic Impact example programs

After completing the training, participants will be able to independently set up, test and modify a basic Datalogic Impact application and send inspection results to a machine control system via digital I/O.
